Hard weld-600(LH)



Hard Facing Electrodes - Hard weld-600(LH)

Characteristics :
A medium heavy coated, low hydrogen, air hardening type hard facing electrode. It gives non-machinable hard deposits of 600 BHN. The low hydrogen coating enables its use on high carbon/sulphur steels without under bead cracking or porosity. It yields hard surface deposits, resistant to heavy-abrasion and moderate impact. When a heavy deposit is required, the initial and intermediate layers may be deposited with Premier-7016 using Hardweld 600 (LH) for final two or three layers.

Applications :
Hot & cold punching dies, Oil expellers, Worms, Pan mixer blades, Dredger bucket lips, Drill bits, Caterpillar threads, Punches, Dies, Dipper teeth, Disintegrator Hammers, Sprockets, Cane & Bamboo cutting knives etc.

Typical Weldmetal Composition

 Element

Percent

C 0.40-0.65
Mn 1.00-1.25
Si 0.50-0.75
Cr 4.00-6.00
Mo 0.70-1.10
V 0.40-0.80

Current Range & Packing Data :


Size MM DxL

Current Range (Amps) AC or DC (-)

Pieces per Packet

Pieces per Carton

5.00x450 170-210 45 180
4.00x450 120-170 80 320
3.15x450 90-120 110 440

Hardness :

550-640 BHN approximately on 3 layer deposit.
